Nanjing Hongbo Metal Products Co., Ltd. jin_song@njhongbo.com 86--15105151079
Product Details
Place of Origin: Nanjing, China
Model Number: HTP
Payment & Shipping Terms
Minimum Order Quantity: 1000 kilograms
Price: $0.90 - $1.50/kilograms
Packaging Details: Stretch film+carton strip+plywood stick+plywood pallet leg+packing belt
Supply Ability: 2000 Kilogram/Kilograms per Month
Type: |
Selective Pallet Rack |
Material: |
Steel |
Feature: |
Corrosion Protection |
Use: |
Warehouse Rack |
Depth: |
800-1500mm |
Weight Capacity: |
500-4000kgs/pair Beam |
Width: |
1000-3900mm |
Height: |
1500-12000mm |
Usage: |
Industry |
Color: |
Blue, Orange, Yellow, Green Etc. |
Port: |
Nanjing, Shanghai |
Type: |
Selective Pallet Rack |
Material: |
Steel |
Feature: |
Corrosion Protection |
Use: |
Warehouse Rack |
Depth: |
800-1500mm |
Weight Capacity: |
500-4000kgs/pair Beam |
Width: |
1000-3900mm |
Height: |
1500-12000mm |
Usage: |
Industry |
Color: |
Blue, Orange, Yellow, Green Etc. |
Port: |
Nanjing, Shanghai |
| Beam size(mm) | beam length(mm) | ||||||||
| 1400 | 1500 | 1900 | 2300 | 2500 | 2700 | 2900 | 3300 | 3600 | |
| Load(kg) | |||||||||
| 80*50*1.5 | 3854 | 3358 | 2092 | 1428 | 1209 | 1036 | 898 | 694 | 583 |
| 90*50*1.5 | 2797 | 1909 | 1616 | 1386 | 1201 | 927 | 779 | ||
| 100*50*1.5 | 3511 | 2397 | 2028 | 1739 | 1507 | 1164 | 978 | ||
| 110*50*1.5 | 2994 | 2534 | 2173 | 1883 | 1454 | 1222 | |||
| 120*50*1.5 | 3671 | 3107 | 2664 | 2309 | 1783 | 1499 | |||
| 130*50*1.5 | 4287 | 3629 | 3111 | 2697 | 2083 | 1750 | |||
| 140*50*1.5 | 3831 | 3320 | 2564 | 2155 | |||||
| 160*50*1.5 | 3475 | 2920 | |||||||
